Features:

This device is used for centralized processing of thermostat signals and is suitable for floor heating systems, gas boilers, hot water boiler circulation pumps, etc.

It can send instructions to control the opening/closing of heating electric valves to achieve regional temperature control.

It is easy and quick to install and easy to use, providing a comfortable environment for the family and reducing energy consumption.

It displays the working status of sub-controllers, power supply, output signals, etc. on the same LED lights at the same time, which is convenient and intuitive.

It uses high-quality materials, is fireproof and flame retardant, has good stability, good insulation, and is safe to use.

Specifications:

Part name:Water Floor Heating Control Box

Color: white

Zone: Max 8

Material: ABS+PC

Specifications: wired and wireless, wires need to be purchased by yourself

Maximum output current: 10A

Power supply: 90-240VAC 50/60Hz

Working environment temperature: -20℃~60℃

Storage temperature: -20℃~70℃

Size: 28*11*4cm/11*4.3*1.6 inches
